3220 28"W x 20' L Stage

3220

Werner Co.

The 3200 stage platforms offer a 750 pound duty rating and allows for 3 people on one plank. The TWIST-PROOF design is ideal for ladder jack applications, swing stages or catwalks. Each stage is 28" wide.
(click image to enlarge)
Quick Overview

    Features include:

  • Individual slip-resistant decking minimizes paint or material build-up
  • Vinyl-coated end caps serve as hand grips and protect from sharp edges and surface marks
  • Double end rung provides extra rigidity on stages 20' or longer
  • 3-Person - 750 lbs. Rated
Interested in this item or want more information?
8:00am - 5:00pm Monday thru Friday
Phone: 1-800-821-4927
Email: Sales@marathontool.com

Can't find what you want? Give us a call and we can help you find it.
Details

Dimensions

  • Side Rail Depth: 5"
  • Side Rail Flange: 2"

    • Specifications

  • Side Rail Length: 20'
  • Platform Width: 28"
  • Load Capacity: 750 lbs.
  • Certifications: ANSI A10.8 (2001); OSHA
  • Approx. Cu. Ft. Per Unit: 19.57
  • Approx. Shipping Wt. Lbs.: 128

    • Additional 3200 Series Models:

    Model No.Side Rail LengthApprox. Cu. Ft. Per UnitApprox. Shipping Wt. Lbs.
    32088'6.1548
    321212'9.2371
    321616'15.66103
    322020'19.57128
    322424'27.96161
    322828'32.62220
    323232'37.28251
    323636'41.94344
    323939'45.44388
    Additional Information
    Manufacturer: Werner Co.
