Features & Specs

FEATURES

• 4.0 CFM delivered at 90 PSI pump provides rapid recovery
• Oil lubricated pump improves durability
• Cast iron cylinder enhances pump life
• 10" pneumatic wheel and handle kit for ease of mobility
• Top load panel with positioning holes allows unit to transport loads up to 100 lbs
• High-flow regulator for increased performance
• Run multiple tools from dual universal quick couplers
• Ball valve drain allows for quick and thorough tank draining
• Convenient cord wrap for easy storage
• Dual soft start valves assist in cold weather start-up

Specifications

• CFM @ 100 PSI 3.8; 4,6@40PSI; 4.2@60PSI, 3.2@125PSI CFM
• Drive Direct
• Horsepower 1.1 HP
• Power Supply 120V AC, 15 amps, 60 Hz, 2 pole induction motor
• Pump Speed 3,400 rpm
• Shipping Weight 95 lbs
• Tank Size 4 gal
• Tool Height 23.0 in
• Tool Length 22.0 in
• Tool Weight 87 lbs
• Tool Width 18.5 in

Includes

• DEWALT® Compressor Oil
• control panel with (2) universal quick couplers
